Plate Heat Exchanger Frame Carbon Steel and Stainless Steel Material Options

MOQ:	1 set
Price:	USD100-10000/set
Standard Packaging:	Plywood case
Delivery Period:	10 - 15 work days
Payment Method:	T/T, L/C, D/A, D/P, Western Union
Supply Capacity:	500 pcs per month

Details Information

Product Description

Detail Information

Place of Origin

China

Brand Name

NONE

Frame Color:

Blue, Red, Grey, Customized

Gaskets Material:

NBR, EPDM, VITON, HNBR, CR

Plate Material:

SS304/316, Ti, Nickle, SMO254

Structure:

Plate Heat Exchanger

Condition:

New

Warranty:

1 Year

Product Description

A Plate Heat Exchanger (PHE) is an efficient and compact heat transfer device designed for various industrial applications. It consists of a series of corrugated metal plates that create multiple channels for hot and cold fluids to flow through, enabling effective heat exchange. PHEs offer advantages such as high thermal efficiency, space-saving design, easy maintenance, and scalability.

Industry Applications & Case Studies

Industry	Common Applications
HVAC & Cooling	District heating, air conditioning, heat recovery
Food & Beverage	Pasteurization, dairy processing, brewing
Chemical Industry	Process heating, solvent recovery, cooling
Power Generation	Turbine & generator cooling, lubrication oil cooling
Marine & Offshore	Engine cooling, seawater desalination
Pharmaceuticals	Sterilization, precise temperature control

Case Study Example:

• Food Industry: A leading dairy company reduced energy consumption by 30% by switching to a customized gasketed plate heat exchanger for pasteurization.

• Power Plants: Implementation of welded PHEs improved efficiency in cooling turbine lubrication systems, extending equipment lifespan.

Key Features & Advantages

High Efficiency & Performance

• Up to 90% heat transfer efficiency, significantly reducing energy consumption.

• Corrugated plate design increases turbulence, enhancing heat exchange rates.

Space-Saving & Lightweight

• Compact design reduces installation footprint compared to shell-and-tube exchangers.

• Lightweight construction allows for easy installation and handling.

Easy Maintenance & Cleaning

• Detachable plates allow for easy cleaning, inspection, and gasket replacement.

• Less fouling & clogging due to high turbulence, reducing downtime.

Customizable Design

• Wide selection of plate and gasket materials to suit different working conditions.

• Flexible configurations available, including gasketed, brazed, and welded PHEs.

Durable & Long-Lasting

• Corrosion-resistant materials such as stainless steel, titanium, and Hastelloy ensure long service life.

• Designed to withstand high pressure and temperature in industrial environments.

Technical Specifications

Parameter	Specification
Plate Material	SS304, SS316L, Titanium, Hastelloy, Duplex Stainless Steel
Gasket Material	NBR, EPDM, Viton
Frame Material	Carbon Steel, Stainless Steel, Epoxy-Coated Steel
Max Temperature	Up to 200°C (392°F)
Max Pressure	Up to 25 bar (360 psi)
Heat Transfer Area	0.1 – 1000 m²
Flow Rate	1 – 5000 m³/h
Plate Thickness	0.5 – 1.0 mm
Channel Gap	2 – 5 mm (customizable)
Connection Type	Threaded, Flanged, Welded
Efficiency	Up to 90%

We can supply below models, include design new compelete PHE unit, plates and gaskets spare parts for old PHE unit. These aren't our all models, if your model is not showed, please don't worry, please contact us.

AL series	M3, M6, M6M, M10, M10M, M15, M15M, M20, M20M, M30 TL6B, TL10B, TL10P, TL20P, TL35B T20S, T20M, T20B, T45M P16, P26, P36 CLIP/FRONT 6, CLIP/FRONT 8, CLIP/FRONT 10 M6BW, M10BW, MK15BW, M20MW etc.......
Sondex series	S4A, S7A, S8A, S9A, S14A, S20A, S19A, S31A, S17, S21, S21A, S22, S37, S41, S41A, S42, S43, S47, S50, S62, S65, S67, S81, S86, S100, S110, S121, S136, S188, S201, SF11, SF53, SF123 etc......
APV series	A055, A085, A145 B063, B110S, B110L, B110M, B134M, B134S, B158M, B158S, B205M, B205S H12, H17 J060, J092, J107, J185 M20, M60, M66, M092, M107, M185 N25, N35, N50 Q030, Q055, Q080 etc..........
GEA series	VT04, VT10, VT20, VT40, VT80, VT130, VT402, VT405, VT805, VT1306, VT2508 NT50, NT100, NT150, NT250, NT350, NT500 N40 FA157, FA159, FA161, FA184, FA192 etc........
Tranter / Swep series	GX7, GX8, GC8, GC9, GC12, GL13, GC16, GX18, GC26, GX26,GX42, GX51, GC51, GC60, GX60, GX100, GX140, GX145 etc.......
Vicarb / Viex series	V4, V8, V13, V20, V28, V45, V60, V85, V100, V110, V130, V170 etc........
Funke series	FP04, FP05, PF08, FP09, FP10, FP16, FP22, FP14, FP20, FP205, FP31, FP40, FP50, FP71, FP41, FP60, FP80, FP112, FP82, FP130 etc........
API series	Sigma7, Sigma9, Sigma13, Sigma16, Sigma26, Sigma36, Sigma56, Sigma66, Sigma156, Sigma229 etc.........
Thermowave series	TL50, TL90, TL150, TL250, TL400, TL500, TL650, TL850
Hisaka series	LX01, LX10B, LX20A, LX30B, LX40A, LX60A UX01, UX05, UX10, UX20A, UX30, UX40, UX80, UX90 RX10, RX30, RX40, RX70 etc.......
