Frame Design and Spare Parts Available for Plate Heat Exchanger

The Plate Heat Exchanger (PHE) is an advanced heat transfer device designed for high-efficiency thermal exchange between fluids. It consists of a series of corrugated metal plates stacked together, forming separate channels for hot and cold fluids. The plates are sealed with gaskets or permanently brazed/welded, ensuring leak-proof operation. PHEs are widely used in HVAC, power plants, chemical processing, food & beverage, pharmaceuticals, and marine industries.

Working Principle

The Plate Heat Exchanger operates by allowing two separate fluids to flow through alternating channels between the plates. The hot fluid transfers heat to the cold fluid through the thin metal plates, without any direct contact between the two liquids. The high turbulence created by the corrugated plates enhances heat transfer efficiency while minimizing fouling and scaling.

Technical Specifications

Key Features & Advantages

High Efficiency & Performance

• Up to 90% heat transfer efficiency, significantly reducing energy consumption.

• Corrugated plate design increases turbulence, enhancing heat exchange rates.

Space-Saving & Lightweight

• Compact design reduces installation footprint compared to shell-and-tube exchangers.

• Lightweight construction allows for easy installation and handling.

Easy Maintenance & Cleaning

• Detachable plates allow for easy cleaning, inspection, and gasket replacement.

• Less fouling & clogging due to high turbulence, reducing downtime.

Customizable Design

• Wide selection of plate and gasket materials to suit different working conditions.

• Flexible configurations available, including gasketed, brazed, and welded PHEs.

Durable & Long-Lasting

• Corrosion-resistant materials such as stainless steel, titanium, and Hastelloy ensure long service life.

• Designed to withstand high pressure and temperature in industrial environments.

Why Choose Our Plate Heat Exchangers?

✔ Industry-Leading Design – Our advanced plate patterns provide superior heat transfer and durability.

✔ Custom Solutions – We offer tailored designs based on your specific process requirements.

✔ Global Standards Compliance – Our products meet international safety and performance standards.

✔ Reliable Support & Service – Dedicated technical support and after-sales services available worldwide.

We can supply below models, include design new compelete PHE unit, plates and gaskets spare parts for old PHE unit. These aren't our all models, if your model is not showed, please don't worry, please contact  us.

If you don't know the model, please send us below dimensions so that we find the right product for you.

Welcome you inquiry anytime, we will quote best price for your reference.
