Rubber Stainless Steel and Titanium Material Plate Heat Exchanger Frame Liner Collar Options

MOQ:	1 set
Price:	USD100-10000/set
Standard Packaging:	Plywood case
Delivery Period:	10 - 15 work days
Payment Method:	T/T, L/C, D/A, D/P, Western Union
Supply Capacity:	500 pcs per month

Details Information

Product Description

Detail Information

Place of Origin

China

Brand Name

NONE

Frame Color:

Blue, Red, Grey, Customized

Gaskets Material:

NBR, EPDM, VITON, HNBR, CR

Plate Material:

SS304/316, Ti, Nickle, SMO254

Structure:

Plate Heat Exchanger

Condition:

New

Warranty:

1 Year

Product Description

The Plate Heat Exchanger (PHE) is a highly efficient, compact, and versatile heat transfer device designed for various industrial and commercial applications. It consists of multiple thin, corrugated metal plates stacked together to create channels for hot and cold fluids to flow through, facilitating optimal heat transfer. The unique plate design maximizes heat exchange efficiency while maintaining a small footprint, making it an excellent alternative to traditional shell-and-tube heat exchangers.

Features & Benefits

✔ High Heat Transfer Efficiency – Optimized plate design enhances thermal performance.

✔ Compact & Lightweight – Requires less space compared to traditional shell-and-tube heat exchangers.

✔ Easy Maintenance – Plates can be disassembled for cleaning and servicing.

✔ Scalability – Additional plates can be added to increase capacity.

✔ Customizable Design – Available in various plate materials (SS304, SS316, Titanium, etc.) and gasket options.

Technical Specifications

Parameter	Specifications
Plate Material	Stainless Steel (SS304, SS316L), Titanium, Hastelloy
Gasket Material	NBR (Nitrile), EPDM, Viton
Frame Material	Carbon Steel, Stainless Steel, Epoxy-Coated Steel
Maximum Operating Temperature	Up to 200°C (392°F)
Maximum Working Pressure	Up to 25 bar (360 psi)
Heat Transfer Area	0.1 – 1000 m²
Flow Rate	1 – 5000 m³/h
Plate Thickness	0.5 mm – 1.0 mm
Channel Gap	2 – 5 mm (customizable)
Connection Type	Threaded, Flanged, Welded
Heat Transfer Efficiency	Up to 90%

Applications

Plate Heat Exchangers are widely used across multiple industries due to their efficiency and adaptability. Some key applications include:

• HVAC & Refrigeration – Air conditioning, heat recovery, and district heating/cooling systems.

• Chemical & Petrochemical Industry – Process heating, cooling, and solvent recovery.

• Food & Beverage Processing – Pasteurization, dairy processing, and brewing.

• Pharmaceutical Industry – Precise temperature control in drug production.

• Power Generation – Cooling of turbines, generators, and oil lubrication systems.

• Marine & Offshore Systems – Engine cooling, fresh water production, and oil refining.

We can supply below models, include design new compelete PHE unit, plates and gaskets spare parts for old PHE unit. These aren't our all models, if your model is not showed, please don't worry, please contact us.

AL series	M3, M6, M6M, M10, M10M, M15, M15M, M20, M20M, M30 TL6B, TL10B, TL10P, TL20P, TL35B T20S, T20M, T20B, T45M P16, P26, P36 CLIP/FRONT 6, CLIP/FRONT 8, CLIP/FRONT 10 M6BW, M10BW, MK15BW, M20MW etc.......
Sondex series	S4A, S7A, S8A, S9A, S14A, S20A, S19A, S31A, S17, S21, S21A, S22, S37, S41, S41A, S42, S43, S47, S50, S62, S65, S67, S81, S86, S100, S110, S121, S136, S188, S201, SF11, SF53, SF123 etc......
APV series	A055, A085, A145 B063, B110S, B110L, B110M, B134M, B134S, B158M, B158S, B205M, B205S H12, H17 J060, J092, J107, J185 M20, M60, M66, M092, M107, M185 N25, N35, N50 Q030, Q055, Q080 etc..........
GEA series	VT04, VT10, VT20, VT40, VT80, VT130, VT402, VT405, VT805, VT1306, VT2508 NT50, NT100, NT150, NT250, NT350, NT500 N40 FA157, FA159, FA161, FA184, FA192 etc........
Tranter / Swep series	GX7, GX8, GC8, GC9, GC12, GL13, GC16, GX18, GC26, GX26,GX42, GX51, GC51, GC60, GX60, GX100, GX140, GX145 etc.......
Vicarb / Viex series	V4, V8, V13, V20, V28, V45, V60, V85, V100, V110, V130, V170 etc........
Funke series	FP04, FP05, PF08, FP09, FP10, FP16, FP22, FP14, FP20, FP205, FP31, FP40, FP50, FP71, FP41, FP60, FP80, FP112, FP82, FP130 etc........
API series	Sigma7, Sigma9, Sigma13, Sigma16, Sigma26, Sigma36, Sigma56, Sigma66, Sigma156, Sigma229 etc.........
Thermowave series	TL50, TL90, TL150, TL250, TL400, TL500, TL650, TL850
Hisaka series	LX01, LX10B, LX20A, LX30B, LX40A, LX60A UX01, UX05, UX10, UX20A, UX30, UX40, UX80, UX90 RX10, RX30, RX40, RX70 etc.......

If you don't know the model, please send us below dimensions so that we find the right product for you.
