Professional Plate Heat Exchanger Unit Design And Spare Parts Supply Customized Options

A Plate Heat Exchanger (PHE) is an advanced and highly efficient heat transfer device designed for industrial and commercial applications. It consists of multiple corrugated metal plates that form alternating channels for hot and cold fluids to pass through, enabling rapid and efficient heat exchange. Due to its compact size, excellent heat transfer performance, and ease of maintenance, it is widely used across industries such as HVAC, chemical processing, food & beverage, power generation, marine, and pharmaceuticals.

Working Principle

The Plate Heat Exchanger operates by allowing two fluids (hot and cold) to flow through alternating channels formed between the plates. Heat is transferred from the hot fluid to the cold fluid through the thin metal plates, ensuring an efficient heat exchange process. The corrugated plate pattern enhances turbulence, increasing thermal performance while minimizing fouling and scaling.

Technical Specifications

Key Features & Benefits

✅ High Thermal Efficiency – Advanced plate designs enhance heat transfer rates, reducing energy consumption.

✅ Compact & Space-Saving – A modular design allows high capacity within a small footprint.

✅ Easy Maintenance & Cleaning – The plates can be easily removed for cleaning, servicing, and gasket replacement.

✅ Flexible & Scalable – The modular structure allows easy expansion by adding more plates.

✅ Customizable Materials – Available in different materials such as SS304, SS316, Titanium, and Hastelloy for various applications.

✅ Low Fouling & High Corrosion Resistance – Optimized design reduces scaling and clogging while ensuring durability in harsh conditions.

Types of Plate Heat Exchangers

Installation & Maintenance

Installation Guidelines:

• Ensure proper alignment of plates and gaskets during assembly.

• Install on a stable, vibration-free surface to prevent damage.

• Use correct inlet/outlet piping to maintain optimal fluid distribution.

• Regularly check pressure and temperature settings to avoid overloading.

Maintenance Tips:

• Periodically inspect and replace gaskets if worn or damaged.

• Clean plates regularly using CIP (Clean-in-Place) methods to prevent fouling.

• Check for any leaks or pressure drops, which may indicate a need for servicing.

• Store spare gaskets and plates for quick replacements when needed.

Why Choose Our Plate Heat Exchangers?

✔ Premium Quality Materials – High-grade stainless steel, titanium, and Hastelloy available.

✔ Custom-Built Solutions – Designed to match your process requirements.

✔ Energy-Efficient Design – Optimized plate patterns maximize heat transfer efficiency.

✔ Global Standards Compliance – CE, ASME, ISO 9001 certified for industrial use.

✔ Expert Technical Support – Dedicated assistance for installation and troubleshooting.

If you don't know the model, please send us below dimensions so that we find the right product for you.

if you need design new PHE unit, please send us below information.

Welcome you inquiry anytime, we will quote best price for your reference.
